IWC 375

Automatic · 12.5‴ · Switzerland · 1978

Also known as: ETA 2892

Dimensions
28.4 mm
Height
3.60mm
Jewels
22
Power reserve
42h
Timegrapher
Beat rate
28,800bph
Frequency
4Hz
Lift angle
53°

Reference: healthy amplitude ≈ 270–315° fully wound (>200° at 24 h); beat error ideally < 0.5 ms.

Movement
Movement type Automatic
Winding type Automatic (Rotor-Driven)
Setting type Stem Set (Crown Pull)
Escapement type Swiss Lever
Control type Balance Wheel
Regulator type Pinned Regulator (or Index Regulator)
Rotor type Central Rotor
Shock protection Incabloc
Specifications
Lignes 12.5‴
Shape Round
Complications Sweep Second , Date , Chronograph Stopwatch
Hand count 3
Hand sizes 1.50 x 0.90 x 0.25mm
Further measures
Mounting Diameter (Dm): 28.0mm
Ball Bearing: 0.1mm
Stem height (T): 1.5mm
Mounting Height (F): 1.1mm
Origin & References
Manufacturer IWC
Base caliber ETA 2892
Country Switzerland
Launch year 1978
COSC certified No
Signature
1) 1979: 2303561, IWC, International Watch Co. Swiss; Incabloc (31 jewels) 2) 1981: 2339418, IWC, International Watch Co. Swiss; Incabloc
Notes
Remarks: 1978-
first ETA base movement at IWC,
rotor weight 21K gold,
option: rotor bearing with 9 ruby balls,
for technical details cf. ETA 2892
Other data: balance staff: ETA 2890 stem: ETA 2890 mainspring / battery: 1.05 x 10.5 x 0.115 x 475mm stem ronda: 2005 (11,5) Other data: stem ronda: 2005 (11,5)
